Front brake disc
- Ultra hardened 420 (2Cr13) stainless steel & 6061-T6 aluminum disc delivers maximum stopping power and greatly enhances braking performance.
- Hi-end laser cut technology. Laser cut for perfection and accuracy.
- Heat treated for warp resistance.
- The vented slots & holes ensure water and dirt are dispersed quickly & speed up air circulation to improve heat dissipation.
- Surfaces are electro-statically coated to ensure a long term appearance.
- No additional spacers or hardware and bolt needed, directly in place of your OEM brake rotors.
Specifications
Outer diameter: 320mm
Inner diameter: 64mm
Thickness: 5mm
Hole quantity: 6
Hole size: 8.4mm
Hole spacing: 80mm
Offset height: 10mm
Rear brake disc
- Anti-corrosion 420(2Cr13) stainless steel with heat treated for strong & reliable braking power & warp resistance.
- Wave shape brake disc rotor 30% light wieght than OEM.
- Slotted rotor ensures water & dirt are dispersed quickly to prevent mud and dirt from interfering with braking performance.
Specifications
Outer diameter: 240mm
Inner diameter: 110mm
Thickness: 5mm
Hole quantity: 6
Hole size: 6.4mm
Hole spacing: 124mm
Please replace your rotor when it reaches the minimum thickness we marked on the surface to ensure your safety
